Prothane Polyurethane Front Sway Bar & End Link Bushing Kit | 2WD (1979-88 Pickup)

Prothane Front Sway Bar & End Link Bushing Kit

For 1979–1988 Toyota Pickup 2WD with 18 mm or 25 mm Front Sway Bars

Overview

The Prothane Front Sway Bar & End Link Bushing Kit replaces worn factory rubber sway-bar frame bushings and end-link bushings on 1979–1988 Toyota Pickup 2WD models. Polyurethane construction provides a firmer, more durable connection between the sway bar and chassis while retaining a direct-fit service configuration.

Two sway-bar diameters are available: 18 mm and 25 mm. The installed front sway bar must be measured before ordering because the two configurations are not interchangeable.

Key Features

• Polyurethane front sway-bar frame bushings
• Polyurethane end-link bushings
• 18 mm and 25 mm front sway-bar configurations
• Black and red color options
• Replacement end-link hardware included
• Prothane Super Grease included for sway-bar bushing installation
• One kit services both front sides

Sway Bar Diameter Selection

Measure the actual front sway bar before ordering.

• 18 mm: Approximately 0.70 in.
• 25 mm: Approximately 0.98 in. / 1 in.

Measure the solid sway bar itself rather than the outside of the existing bushing or bracket.

Vehicle Fitment

Toyota Pickup

• 1979–1983 Toyota Pickup – 1st Gen – 2WD – 18 mm or 25 mm front sway bar
• 1984–1988 Toyota Pickup – 2nd Gen – 2WD – 18 mm or 25 mm front sway bar

Fitment Notes

• 2WD Toyota Pickup only
• Front application
• 18 mm and 25 mm configurations are not interchangeable
• Choose the kit based on the actual installed sway-bar diameter
• The 18 mm kit is specific to 1979–1988 Pickup 2WD

• Apply the supplied polyurethane grease to the sway-bar bushing contact surfaces during installation

Product Specifications

Brand: Prothane
Product Type: Suspension & Steering
Component Type: Bushing
Position: Front
Bushing Material: Polyurethane
Hardware Material: Steel
Sway Bar Diameter Options: 18 mm / 25 mm
Color Options: Black / Red
Coverage: Left & Right Front
Drivetrain: 2WD
Fit Type: Vehicle-Specific
Installation Lubricant: Prothane Super Grease Included

Available Configurations

Sway Bar Diameter

• 18mm
• 25mm

Color

• Black
• Red

Each configuration includes:

18 mm Configuration

• (2) 18 mm front sway-bar bushings
• (4) End-link bushings
• (4) Dished washers
• (2) Metal sleeves
• (2) End-link bolts
• (2) Nylon lock nuts
• (2) Sway-bar brackets
• (1) Prothane Super Grease packet

25 mm Configuration

• (2) 25 mm front sway-bar bushings
• (8) End-link bushings
• (8) Dished washers
• (2) Metal sleeves
• (2) End-link bolts
• (2) Nylon lock nuts
• (1) Prothane Super Grease packet

Supporting Suspension Components

For a broader front suspension refresh, the Prothane Polyurethane Front Control Arm Bushing Kit | 2WD (1979-95 Pickup) services the front upper and lower control-arm bushings, while the Prothane Polyurethane Front Strut Rod Bushing Kit | 2WD (1979-95 Pickup) replaces the front strut-rod bushings. These components address separate front suspension pivot points and can be used alongside the sway-bar and end-link kit when those areas also require service.
