Prothane Polyurethane Front Sway Bar Bushings Kit 2WD (1979-88 Pickup)

SKU: 612
(0)
$36.92
Sway Bar Diameter
Color
Fitment support available
Estimate shipping before checkout

Prothane Front Sway Bar Bushing & End Link Kit – 18mm / 25mm

For 1979–1988 Toyota Pickup 2WD

Overview

The Prothane Front Sway Bar Bushing & End Link Kit replaces worn factory rubber sway bar mounting and end-link bushings on 1979–1988 Toyota Pickup 2WD models. Two configurations are available for trucks equipped with either an 18mm or 25mm front sway bar.

The polyurethane bushings provide a firmer connection between the sway bar, chassis, and end links, helping reduce unwanted bushing deflection and maintain more consistent sway bar operation. Each kit also includes application-specific end-link components and polyurethane installation grease.

Because both sway bar diameters are supported within this vehicle range, physically measure the installed front sway bar before ordering rather than selecting a kit solely by model year or engine.

Key Features

  • Complete front sway bar bushing and end-link kit
  • Available for 18mm or 25mm front sway bars
  • Designed for Toyota Pickup 2WD
  • Polyurethane replacement for factory rubber bushings
  • Services both driver and passenger sides
  • Includes frame-mounted sway bar bushings
  • Includes application-specific end-link bushings and hardware
  • Helps reduce unwanted sway bar movement and bushing deflection
  • Polyurethane installation grease included
  • Available in black or red

Choosing the Correct Sway Bar Size

The 18mm and 25mm configurations are not interchangeable. The frame-mounted bushings must closely match the actual sway bar diameter to properly support the bar without excessive clearance or binding.

18mm Front Sway Bar

  • Approximately 0.70 inch

25mm Front Sway Bar

  • Approximately 0.98 inch / 1 inch

Digital or vernier calipers provide the most accurate measurement. An 18mm open-end wrench can also provide a quick check on a clean, straight portion of the sway bar, but a bar that does not fit the wrench should be measured directly rather than automatically assumed to be 25mm.

Vehicle Fitment

Toyota Pickup

  • 1979–1983 Toyota Pickup – 1st Gen – 2WD – 18mm or 25mm Front Sway Bar
  • 1984–1988 Toyota Pickup – 2nd Gen – 2WD – 18mm or 25mm Front Sway Bar

Fitment Notes

  • 2WD Toyota Pickup only
  • Front application
  • Choose 18mm or 25mm based on the actual installed sway bar diameter
  • 18mm and 25mm configurations are not interchangeable
  • One kit services both driver and passenger sides
  • Measure the installed sway bar before ordering, particularly if suspension components have previously been replaced or modified
  • Apply the supplied polyurethane grease to the required sway bar bushing contact surfaces
  • Inspect sway bar brackets, end links, and mounting hardware before installation
  • The 25mm kit is also used on later Toyota Pickup 2WD applications, but this listing is specifically configured for 1979–1988 models

Product Specifications

Brand: Prothane
Product Type: Front Sway Bar Bushing & End Link Kit
Position: Front
Material: Polyurethane / Steel
Sway Bar Diameter Options: 18mm / 25mm
Color Options: Black / Red
Coverage: Driver & Passenger Sides
Drivetrain: 2WD
Fitment Type: Vehicle Specific
Installation Grease: Included

Available Configurations

18mm Front Sway Bar

  • (2) 18mm front sway bar bushings
  • (4) End-link bushings
  • (4) Dished washers
  • (2) Metal sleeves
  • (2) End-link bolts
  • (2) Nylon lock nuts
  • (2) Sway bar brackets
  • (1) Polyurethane installation grease packet
  • Available in Black or Red

25mm Front Sway Bar

  • (2) 25mm front sway bar bushings
  • (8) End-link bushings
  • (8) Dished washers
  • (2) Metal sleeves
  • (2) End-link bolts
  • (2) Nylon lock nuts
  • (1) Polyurethane installation grease packet
  • Available in Black or Red
