AE86 Koyo HH Series 48mm Aluminum Radiator | 4A-GE (1983-87 Corolla)

Koyo HH Series 48mm Aluminum Performance Radiator

For 1983–1987 Toyota Corolla AE86 Trueno / Levin and 1985–1987 U.S.-Market Corolla Sport AE86 GT-S with 4A-GE and Manual Transmission

Overview

The Koyo HH Series 48mm Aluminum Performance Radiator is a direct-fit cooling upgrade for 4A-GE-powered Toyota AE86 applications with a manual transmission. Its high-density 48mm HH Series core increases cooling capacity while retaining vehicle-specific mounting and factory-style integration.

All-aluminum construction, Nocolok brazing, precision tube-and-fin alignment, and hand-finished aluminum welds provide a durable performance radiator for street, drift, track, and restored AE86 builds.

Key Features

• 48mm HH Series high-density aluminum core
• All-aluminum performance radiator construction
• Nocolok-brazed core with precise tube-and-fin alignment
• Billet aluminum filler neck
• Integrated 1/8-inch NPT female accessory port with threaded plug
• Vehicle-specific direct-fit mounting
• Retains OEM fan-shroud mounting points
• Retains factory radiator hose connections

Vehicle Fitment

• 1983–1987 Toyota Corolla AE86 – Trueno (JDM) – 1.6L 4A-GE – Manual Transmission
• 1983–1987 Toyota Corolla AE86 – Levin (JDM) – 1.6L 4A-GE – Manual Transmission
• 1985–1987 Toyota Corolla Sport AE86 – GT-S (U.S.-Market) – 1.6L 4A-GE – Manual Transmission

Fitment Notes

• 4A-GE engine only
• Manual transmission only
• Does not fit 4A-C / SR5 applications
• Does not fit automatic-transmission applications
• Uses factory radiator mounting locations
• OEM fan-shroud mounting points and factory radiator hose connections are retained
• No cutting or vehicle modification is required for the listed applications

Product Specifications

Brand: Koyo
Series: HH Series
Product Type: Performance Radiator
Core Thickness: 48 mm
Construction: All Aluminum
Engine: 1.6L 4A-GE
Transmission: Manual
Chassis: AE86
Core Construction: Nocolok Brazed
Filler Neck: Billet Aluminum
Accessory Port: 1/8-Inch NPT Female
Installation: Vehicle-Specific / Direct Fit

Alternative AE86 Radiator for 4A-C & Dual-Fan Setups

This Koyo radiator is intended for 4A-GE manual-transmission AE86 applications. The AE86 Mishimoto Performance Aluminum Radiator is a separate radiator alternative for supported AE86 applications that include the 4A-C, and it is also available with a matched dual-electric-fan shroud package. It is not required with the Koyo radiator; it is an alternative cooling configuration with different fitment and included hardware.

What's Included

• (1) Koyo HH Series 48mm all-aluminum performance radiator
• (1) Threaded accessory-port plug

Radiator cap is sold separately.
