DENSO Ignition Wire Set | 4A-GE (1985-89 MR2 / 1988-89 Corolla)

DENSO Ignition Wire Set

For 1985–1989 Toyota MR2 AW11 and 1988–1989 Toyota Corolla AE92 coupe equipped with naturally aspirated 4A-GE engines and original distributor-and-coil ignition.

Overview

This DENSO First Time Fit ignition wire set replaces the high-voltage leads between the distributor, spark plugs and ignition coil on 1985–1989 U.S.-market MR2 AW11 and 1988–1989 U.S.-market Corolla AE92 GT-S with the naturally aspirated 4A-GE and original distributor-and-coil ignition. Supercharged 4A-GZE, later GT-S and Japanese-market AE92 applications are not covered.

Each lead is supplied pre-cut to length with terminals and boots already fitted. The assembled design matches the original ignition-wire connections.

Key Features

• 7 mm wire diameter for the original wire-management arrangement.
• Silicone insulation and outer jacket resist engine-bay heat, cold, chemicals and moisture.
• SAE J2031 Class E construction for high-temperature ignition-wire service.
• Click-in terminals provide a positive indication that the connections are seated.
• EMI/RFI suppression helps control electrical interference from the ignition system.

Vehicle Fitment

Toyota MR2 — AW11 / MK1

• 1985–1989: U.S.-Market / Naturally aspirated 4A-GE

Toyota Corolla — AE92 coupe

• 1988–1989: GT-S coupe (U.S.-Market) / naturally aspirated 4A-GE / original distributor-and-coil ignition

Fitment Notes

• AE92 coverage is the early U.S.-market GT-S only. Original August 1987–August 1989 production ignition-wire arrangement; 1990–1991 GT-S, 4A-F / 4A-FE and Japanese-market applications are not included.
• Alternative coil leads are supplied for the listed original routing arrangements. Select the lead matching the vehicle's original coil location and connections; both coil leads are not used together.
• Does not fit supercharged 4A-GZE models.
• Engine swaps, altered distributors or coils, and coil-on-plug conversions require ignition-specific wire selection.

For the listed AW11 application, if the spark plugs are also due for replacement, the DENSO Spark Plug Set for Toyota MR2 AW11 provides a separate four-plug service option. Spark plugs are not included with this wire set. The linked plug listing is not an AE92 fitment recommendation.

Product Specifications

Brand: DENSO
Series: First Time Fit
Product type: Ignition wire set
Spark-plug boot angle: 105°
Spark-plug end terminals: Female
Distributor/coil end terminals: Male
Spark-plug boot construction: Silicone / PBT / silicone

What's Included

• (4) Spark-plug leads with fitted boots and terminals
• (2) Coil leads with fitted boots and terminals
