AISIN Cooling Fan Clutch | Manual 20R / 22R / 22RE (1979-92 Pickup)

AISIN Cooling Fan Clutch

For 1979–1992 Toyota Pickup 2WD with Manual Transmission

Overview

AISIN cooling fan clutches regulate engine-driven fan speed as cooling demand changes, helping provide airflow at low vehicle speed without keeping the fan fully engaged at all times. This listing is specifically for the 2WD manual-transmission Toyota Pickup applications below.

Key Features

• OE-manufacturer engineering — built for factory-style cooling-system operation
• Thermal fan-clutch design — responds to cooling demand as engine temperature changes
• 2WD application — matched to the RWD Toyota Pickup configuration listed below
• Manual-transmission fitment — avoids the automatic-transmission and 4WD fan-clutch branch
• Direct-fit construction — installs with the factory-style mechanical cooling fan system
• New replacement component — not remanufactured

Vehicle Fitment

Toyota Pickup

• 1979–1980 Toyota Pickup – 1st Gen – 2WD – 2.2L 20R – Manual Transmission
• 1981–1983 Toyota Pickup – 1st Gen – 2WD – 2.4L 22R – Manual Transmission
• 1984 Toyota Pickup – 2nd Gen – 2WD – 2.4L 22R – Manual Transmission
• 1985–1988 Toyota Pickup – 2nd Gen – 2WD – 2.4L 22R / 22RE – Manual Transmission
• 1989–1990 Toyota Pickup – 3rd Gen – 2WD – 2.4L 22R / 22RE – Manual Transmission
• 1991–1992 Toyota Pickup – 3rd Gen – 2WD – 2.4L 22RE – Manual Transmission

Fitment Notes

• 2WD and manual transmission only for the applications presented here.
• 4WD applications use a different fan-clutch configuration.
• Automatic-transmission applications use a different fan-clutch configuration.
• 22R-TE turbo applications are excluded from this listing.
• 1993–1995 Toyota Pickup applications are excluded from this listing.
• Engine-swapped vehicles should be matched to the installed water-pump, fan, and fan-clutch configuration rather than chassis year alone.
• When servicing the cooling system, inspect the AISIN OE Water Pump, fan blade, shroud, and drive belts for wear or play.

Product Specifications

Brand: AISIN
Product Type: Cooling
Component Type: Fan Clutch
Fan Type: Mechanical Clutch Fan
Design: Standard Thermal
Drivetrain: 2WD
Transmission: Manual
Condition: New
Sold As: Each

Installation Requirements

Install with the correct factory-style fan blade and mounting hardware for the vehicle. Inspect the water-pump shaft and bearing for play before installation, verify the fan blade and shroud have proper clearance, and confirm the fan rotates freely without contact before starting the engine.

What's Included

• (1) AISIN cooling fan clutch

Important: Fan blade and mounting hardware are not included.
